| Motor-Model No. |
395cc BS III Diesel |
435cc BS III Diesel |
| Tipo |
De cuatro tiempos, refrigerado por aire, DIESEL |
De cuatro tiempos, refrigerado por aire, DIESEL |
| Calibre.MM |
82 |
86 |
| Golpe .MM |
68 |
75 |
| Potencia neta máxima, Potencia Caballos en R / MIN |
7.6 HP @ 3600 rpm |
7.6 HP @ 3600 rpm |
| Torsión neto máximo a / MINKG.M at/MIN |
17 Nm @ 2200 rpm |
18 Nm @ 2400-2200 RPM |
| Tipo de motor |
Enfriador del aire forzado |
| Desplazamiento |
395 cc |
436 cc |
| N º de cilindros |
1 |
| Ratio de compresión |
18:1 |
19:1 |
| Especificación extra |
| sistema de encendido |
CDI |
| Arranque |
Eláctrico + Manual |
| Tipo de embrague |
Húmedo Tipo multidisco |
| transmisión |
4 Delantera + 1 Marcha tras |
| Capacidad del tanque de combustible, litros |
Lleno 7,5 litros, de reserva -1,5 litros |
| sistema eláctrico |
with multiplate with oil bath
|
| faros |
35/35 W |
| Bocina |
12V DC |
| Tipo de chasis |
Tubo rectangular chasis tipo escalera |
| Front Suspension |
Helical coil spring and hydraulic double acting shock absorber |
| Rear Suspension |
Helical coil spring and hydraulic double acting shock absorber |
| Front Tyre Size |
(4.5-10-8)pr cross |
| Rear Tyre Size |
(4.5-10-8)pr cross |
| Brakes |
Drum |
| Reserve
Capacity |
1 litres |
| Wheel Base |
1820mm |
| Ground
Clearance |
130mm |
| Minimum Turning Radius |
2.88m |
| Curb Weight |
400kg |
| Maximum Payload |
500kg |
| Fuel Consumption |
30 to 32 kmpl (Under factory testing conditions) |
| Max Speed |
60 kmph |
| Air Cleaner |
OIL BATH TYPE |
| Oil Filter |
Wire Mesh Type |
| Fuel Filter |
Paper Element Type |
| Capicity of Cooling system |
Air Cooled |
| Fuel Filter |
Paper Element Type |
