| Type |
4 stroke force air cooled
Single cylinder engine |
| Bore, MM |
57 |
| Stroke, MM |
68 |
| Engine Displacement, CC |
198.75 cm3 |
| Maximum Net Power, HP AT R/Min |
7.62 KW @ 6000 rpm/min. |
| Maximum Net torque |
16.7 Nm @4500 rpm |
| Ignition System |
CDI |
| Fuel |
Petrol |
| Lubrication |
Separator oil pump |
| Starting |
Electric Start + Hand Lever option |
| Transmission |
4 Forward + 1 Reverse |
| Fuel Tank Capacity, Litre |
Full 8 Litters |
| Clutch |
Wet Multiplace type |
| Electricals: |
| System |
12 V, DC |
| Battery |
12V 14Ah / 12v 32Ah |
| Head Lamp Twin |
35/35 W |
| Tail Lamp / Stop Lamp |
5/10 W |
| Side Indicator Lamp |
10w |
| Horn |
12V, DC |
| Chassis |
Monocoque |
| Dimensions |
| Length |
2000 MM |
| Width |
1300 MM |
| Height |
1704 MM |
| Wheel Base |
2000 MM |
| Ground Clearance |
200 MM |
| Turning Circular Diameter |
5.8 M |
| Weights In KG. |
| KERB Weight |
290 |
| Maximum Total Weight |
540 |
| Maximum Payload |
250 |
